B-MESH 200

B-Mesh 200 is the resin coated basalt fibre mesh for internal partition and external infill wall anti-overturn protection systems.

image-1
image-1
image-1
image-1
image-1
image-1
image-1
image-1
System description Arrow dropdown

System description

Resin coated basalt fibre mesh for internal partition and external infill wall anti-overturn protection systems.

B-MESH 200 200 g/m2 grammage, basalt fibre mesh, suitable for internal partition and external infill walls anti-overturn protection, used together with the B-JOINT connector and MX-RW High Performance, MX-CP Lime, MX-15 Plaster high-thickness mortars for structural plaster and MX-C 25 Masonry or MX-PBO Masonry low-thickness mortar.

resistenza-fuoco-ruregold-icona
Fire resistant
supporti-umidi-ruregold-icona
Damp substrates
permeabilita-vapore-ruregold-icona
Vapour permeability
prodotto-facile-posa-ruregold-icona
Ease of application
prodotto-ecoogico-ruregold-icona
Bio
Resistente ai cicli di gelo/disgelo
Resistant to freeze/thaw cycles

SYSTEM ELEMENTS:

B-MESH 200

Grammage 200 g/m²
Mesh 25×25 mm
Rolls H 1 m x L 50 m.

MX-RW-High-Performance
MX-RW High Performance

Compressive strength ≥ 45 MPa.

MX-cp-lime-bag-only
MX-CP Lime

NHL 3.5 lime base.
Compressive strength ≥ 15 MPa.

MX-15-plaster
MX-15 Plaster

Compressive strength ≥ 15 MPa.

MX-C 25 Masonry

Compressive strength ≥ 20 MPa

MX-PBO Masonry

Compressive strength ≥ 20 MPa.

B-JOINT-ruregold
B-JOINT

Basalt fibre connector. Available in:

– Ø 10 mm, dispenser 10 m

MX-JOINT

Inorganic matrix for impregnating and anchoring the B-JOINT fibre connector.

MX-NHL MASONRY

NHL Lime base
Compressive strength
≥ 20 MPa.

Applications

campi-applicazione-b-mesh-gold-200-220
  • Wall anti-overturn protection for non-structural elements.
  • Making internal partitions and walls safe.
  • Making external frame infill walls in reinforced concrete safe.
  • Ceiling anti-shatter protection.
